DES-3028 DES-3028P DES-3028G DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Port
The CP
U Access Rule may be configured on a per-port basis by entering the port number of the
Switch.
Time Range
Click the check box and enter the name of the Time Range settings that have been previously
configured in the Time Range window. This will set specific times when this CPU access rule will
be implemented on the Switch.
To view the settings of a previously configured rule, click in the Access Rule Table to view the following window:
Figure 9- 23. CPU Interface Filtering Entry Display window – Ethernet
The following window is the CPU Interface Filtering Rule Table for IP.
Figure 9- 24. CPU Interface Filtering Rule Table window – IP
To create a new rule set for an access profile click the Add button. A new window is displayed. To remove a previously created
rule, click the corresponding
button. The following window is used for the CPU IP Rule configuration.
176
