DES-3028 DES-3028P DES-3028G DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Figure 10- 27. Configure 802.1X Guest VLAN window
The following fields may be modified to enable the guest 802.1X VLAN:
Parameter Description
VLAN Name
Enter the pre-configured VLAN name to create as a Guest 802.1X VLAN.
Operation
The user has two choices in configuring the Guest 802.1X VLAN, which are:
Enabled – Selecting this option will enable ports listed in the Port List below, as part of the Guest
VLAN. Be sure that these ports are configured for this VLAN or users will be prompted with an
error message.
Disabled - Selecting this option will disable ports listed in the Port List below, as part of the
Guest VLAN. Be sure that these ports are configured for this VLAN or users will be prompted
with an error message.
Port List
Set the port list of ports to be enabled for the Guest 802.1X VLAN using the pull-down menus.
Click Apply to implement the guest 802.1X VLAN settings entered. Only one VLAN may be assigned as the 802.1X Guest
VLAN.
Initializing Ports for Port Based 802.1X
Existing 802.1X port and MAC settings are displayed and can be configured using the window below.
Click Security > 802.1X > Initialize Port(s) to open the following window:
Figure 10- 28. Initialize Port window
This window allows initialization of a port or group of ports. The Initialize Port Table in the bottom half of the window displays
the current status of the port(s).
This window displays the following information:
210
