DES-3526 / DES-3526DC Fast Ethernet Layer 2 Switch
96
Figure 6- 64. Access Rule Configuration window (Packet Content Mask)
To set the Access Rule for the Packet Content Mask, adjust the following parameters and click Apply.
Parameter Description
Profile ID
This is the identifier number for this profile set.
Mode
Select Permit to specify that the Switch, according to any additional rule, forwards the
packets that match the access profile added (see below).
Select Deny to specify that packets that do not match the access profile are not
forwarded by the Switch and will be filtered.
Access ID (1-65535)
Type in a unique identifier number for this access or use Auto Assign.
Type
Selected profile based on Ethernet (MAC Address), IP address or Packet Content
Mask.
