xStack DES-3528 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
MLD Snooping Group
The following window allows the user to view MLD Snooping Groups present on the Switch. MLD Snooping is an IPv6
function comparable to IGMP Snooping for IPv4. The user may browse this table by VLAN Name present in the
Switch by entering that VLAN Name in the empty field shown below, and clicking the Find button. The number of MLD
reports that were snooped is displayed in the Reports field.
To view the MLD Snooping Group window, click Monitoring
> MLD Snooping Group.
Figure 11- 30. MLD Snooping Group window
The following field can be viewed:
Parameter Description
VLAN Name
The VLAN name of the MLD multicast group.
Multicast Group
The IP address of the MLD multicast group.
MAC Address
The MAC address of the MLD multicast group.
Reports
The total number of reports received for this group.
NOTE: To configure MLD snooping for the Switch, go to the L2 Features folder and
select MLD Snooping > MLD Snooping Settings.
JWAC Host Table
To view the JWAC Host Table window, click, Monitoring > JWAC Host Table.
Figure 11- 3 . JWAC Host Table window 1
232
