xStack DES-3528 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
The total number of packets (including bad packets) received that were 64 octets in length
(excluding framing bits but including FCS octets).
64
65-127
The total number of packets (including bad packets) received that were between 65 and
127 octets in length inclusive (excluding framing bits but including FCS octets).
128-255
The total number of packets (including bad packets) received that were between 128 and
255 octets in length inclusive (excluding framing bits but including FCS octets).
256-511
The total number of packets (including bad packets) received that were between 256 and
511 octets in length inclusive (excluding framing bits but including FCS octets).
512-1023
The total number of packets (including bad packets) received that were between 512 and
1023 octets in length inclusive (excluding framing bits but including FCS octets).
1024-1518
The total number of packets (including bad packets) received that were between 1024 and
1518 octets in length inclusive (excluding framing bits but including FCS octets).
Show/Hide
Check whether or not to display 64, 65-127, 128-255, 256-511, 512-1023, and 1024-1518
packets received.
Clear
Clicking this button clears all statistics counters on this window.
View Table Clicking this button instructs the Switch to display a table rather than a line graph.
View Graphic Clicking this button instructs the Switch to display a line graph rather than a table.
Packets
The Web Manager allows various packet statistics to be viewed as either a line graph or a table. Six windows are
offered.
Received (RX)
This table displays the RX packets on the Switch. To select a port to view these statistics for, select the port by using
the Port pull-down menu. The user may also use the real-time graphic of the Switch at the top of the web page by
simply clicking on a port.
To view the following graph of packets received on the Switch Click Monitoring > Packets > Received (RX).
210
