xStack DES-3528 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
22
Device Information
This window contains the main settings for all major functions on the Switch and appears automatically when you log
on. To return to the Device Information window, click the DES-3528 Web Management Tool folder. The Device
Information window shows the Switch’s MAC Address (assigned by the factory and unchangeable), the Boot PROM
Version, Firmware Version, and Hardware Version. This information is helpful to keep track of PROM and firmware
updates and to obtain the Switch's MAC address for entry into another network device's address table, if necessary. In
addition, this window displays the status of functions on the Switch to quickly assess their current global status. Some
functions are hyper-linked to their configuration window for easy access from the Device Information window.
Figure 6- 1. Device Information window
System Information
This window contains the System Information details. The user may enter a System Name, System Location and
System Contact to aid in defining the Switch, to the user's preference. This window displays the MAC Address,
Firmware Version and Hardware Version.
Click Configuration > System Information to display the following window:
Figure 6- 2. System Information window
The fields that can be configured are described below:
Parameter Description
System Name Enter a system name for the Switch, if so desired. This name will identify it in the Switch
network.
System Location
Enter the location of the Switch, if so desired.
System Contact
Enter a contact name for the Switch, if so desired.
Click Apply to implement changes made.
