xStack DES-3528 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
• Support Full-Duplex operations
2 1000BASE-T ports in the rear
panel
1000BASE-T ports compliant to following standards:
• IEEE 802.3 compliance
• IEEE 802.3u compliance
• IEEE 802.3ab compliance
• IEEE 802.3x Flow Control support for Full-Duplex mode, back pressure
when Half-Duplex mode, and Head-of-line blocking prevention
FE Port Pin Assignment for Data/Power Pairs: (alternative A MDI-X)
PIN# Signal Descriptions
1 Receive+ Positive Receive signal
2 Receive- Negation Receive signal
3 Transmit+ Positive Transmit signal
4
5
6 Transmit- Negation Transmit signal
7
8
243
