xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
13
The fields that can be displayed are described below:
Parameter Description
Port
Display the port that has been error disabled.
Port State
Describe the current running state of the port, whether enabled or disabled.
Connection Status
Display the uplink status of the individual ports, whether enabled or disabled.
Reason
Describe the reason why the port has been error-disabled, such as it has become a
shutdown port for storm control.
Port Auto Negotiation Information
The following window displays the detailed auto negotiation information.
To view the following window, click System Configuration > Port Configuration > Port Auto Negotiation
Information, as show below:
Figure 2-6 Port Auto Negotiation Information window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit you wish to display.
