xStack® DGS-3620 Series Managed Switch Web UI Reference Guide
250
Figure 5-138 BGP Clear Settings window
The fields that can be configured are described below:
Parameter Description
Type Use the drop-down menu to select IP Address, AS, Peer Group, External, or All.
IP Address - Specify to reset the session with the specified neighbor.
AS - Specify to reset sessions with BGP peers in the specified Autonomous System.
Peer Group - Specify to reset a peer group.
External - Specify all eBGP sessions will be reset.
All - Specify that all current BGP sessions will be reset.
IP Address If IP Address is selected in the Type drop-down menu, enter an IP address.
AS Number (1-65535) If AS is selected in the Type drop-down menu, enter an Autonomous System number.
Peer Group Name If Peer Group is selected in the Type drop-down menu, enter a peer group name.
Mode Option Tick the desired mode option: Soft, In, Prefix Filter or Out.
Soft – This initiates a soft reset. It does not tear down the session.
In – This iInitiates inbound reconfiguration. If neither in nor out keywords are specified,
both inbound and outbound sessions are reset.
Prefix Filter – The local site configured prefix filter will be notified to the remote
neighbor when inbound soft reset is applied.
Out – This initiates outbound reconfiguration.
Click the Apply button to accept the changes made for each individual section.
BGP Summary Table
This window displays the BGP summary information.
To view the following window, click L3 Features > BGP > BGP Summary Table, as shown below:
Figure 5-139 BGP Summary Table window
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
