6D-Link DIR-608 User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 Reset & WPS Button
WPS Press and hold for about one second to start the WPS process to automatically connect a WPS client.
Reset To reset the device to its factory default settings, press and hold the reset button for ve seconds.
2 LAN Ports (1-2) Connects to Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
3 Internet Port Using an Ethernet cable, connect your broadband modem to this port.
4 Power Connector Connector for the supplied power adapter.
1 2 3 4
