5D-Link DIR-608 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 Power LED The Power LED indicates that the devices is powered on with a proper connection to the power supply.
2
Wireless LED
The Wireless LED indicates that the wireless is operating. It blinks during wireless data transmission.
The Wireless LED blinks during the WPS pairing process.
3
Internet LED The Internet LED indicates that an Internet link is established. It blinks during data transmission.
4
LAN Port LEDs (1-2) The LAN Port LEDs indicate an Ethernet device is connected. They blink during data transmission.
1 2 3 4
