6D-Link DIR-615+ User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 Power Connector Connector for the supplied power adapter.
2 Internet Port Using an Ethernet cable, connect your broadband modem to this port.
3 LAN Ports (1- 4) Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
4 WPS/Reset Button
Press to start the WPS process and automatically create an encrypted connection to a WPS client. Long
press the button to reset the router to default settings.
31 2 4
