D-Link DIR-615+ User Manual

55D-Link DIR-615+ User Manual
Section 4 - Conguration
VLAN
VLAN tagging allows for services such as Triple-Play to be used, and divides a
network into segments that can only be accessed by other devices in the same
VLAN.
In the Settings menu on the bar on the top of the page, click Internet, then
click the VLAN link.
Click on any VLAN to congure it. Refer to VLAN Add/Edit on page 56 for
conguration instructions.
VLAN List
Add: Click here to add a new VLAN. Refer to VLAN Add/Edit on page 56
Delete: Click here to delete the selected VLAN.
Name: This column indicates the name of the VLAN.
Type: This column indicates the type of the VLAN.
Untagged Ports: This column indicates the untagged ports belonging to the VLAN.
Tagged port: This column indicates the tagged ports belonging to the VLAN.
VLAN ID: Indicates the VLAN ID to which the tagged ports belong.
Enable: Indicates whether the VLAN is enabled or not.

D-Link DIR-615+ Specifications

General

Device Type	Wireless Router
Frequency Band	2.4 GHz
Wireless Speed	Up to 300 Mbps
Wireless Standards	802.11b/g/n
Wired Ports	4 x 10/100 LAN, 1 x 10/100 WAN
Antenna	2 x External Antennas
Security	WPA, WPA2
Firewall	SPI Firewall
