D-Link DIR-890L User Manual

145D-Link DIR-890L User Manual
Section 6 - Troubleshooting
• Access the web management. Open your web browser and enter the IP address* of your D-Link router in the address bar.
This should open the login page for your web management.
* Note: The default IP address of your DIR-890 is http://192.168.0.1. If you connect the DIR-890L to your existing router in Bridge
Mode, it will be assigned a new IP address based on your router/network’s DHCP settings. You will have to access your other router's
DHCP table to see what IP address was assigned to the DIR-890L. (Refer to the manufacturer's user manual if it is not a D-Link device.)
If you are using a D-Link router, follow these instructions to nd the IP address that was assigned:
Using the router’s Web-based conguration utility, go to Setup > Network Settings. Scroll down to the bottom of the page, below
the heading that says Number of Dynamic DHCP Clients, to view the list of connected devices. Refer to the MAC address that is
printed on the label that is attached to the bottom of the DIR-890L to nd the corresponding IP address.
• If you still cannot access the conguration, unplug the power to the router for 10 seconds and plug back in. Wait about 30
seconds and try accessing the conguration. If you have multiple computers, try connecting using a dierent computer.
2. What can I do if I forgot my password?
If you forgot your password, you must reset your router. Unfortunately, this
process will change all your settings back to factory default.
To reset the router, locate the reset button (hole) on the back of the unit.
With the router powered on, use an unfolded paper clip to press and hold the
button down for about 10 seconds. Release the button and the router will go
through its reboot process. Wait about 30 seconds to access the router.
Reset Button

D-Link DIR-890L Specifications

General

VPN support	PPTP/L2TP/IPsec
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	3200 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Input current	5 A
Rack mounting	No
Frequency band	2.4 & 5 GHz
USB ports quantity	2
WLAN data transfer rates supported	600, 1300 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
DHCP client	-
Antennas quantity	6
Security algorithms	WPA, WPA2, WPS
Product type	Tabletop router
Product color	Red
Certification	IC\\r CE\\r Wi-Fi Certified\\r FCC
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	387 mm
Width	247.3 mm
Height	119.5 mm
Weight	- g
