D-Link DSL-226 User Manual

12D-Link DSL-226 User Manual
Section 2 - Installation
Use the DSL-226 as a router only. Plug one end of the supplied Ethernet cable into the WAN port on the back of the
router and the other end to your existing cable/UFB/NBN™ connection box or modem. Then power on the connection
box.
2-2
Connect the supplied power adapter to the router and a power outlet, and press the power button. The device LEDs
will light up. Wait approximately three minutes before proceeding to the next step.
Caution: Use only the included power adapter with this product.
3
DSL/cable modem
PC
DSL-226
WALL JACK
POWER OUTLET
PC
Note: The WAN/LAN port has to be congured to a physical WAN port. You also need to congure the WAN connection type to
connect to the Internet properly (refer to Internet - Ethernet on page 34).
