D-Link DSL-226 User Manual

49D-Link DSL-226 User Manual
Section 4 - Conguration
Advanced Settings
Clicking Advanced Settings allows you to manually congure security,
wireless radio operation, and schedule settings.
Security:
Choose None, WEP (WEP-128Bit, WEP-64Bit), WPA (WPA2, WPA
or WPA2/WPA). Select None for unsecured network if it is what you
intend. The default is WPA2 with pre-shared key.
WPA
Wi-Fi Protected Access (WPA) oers stronger encryption algorithm than WEP
(Wired Equivalent Privacy) with dynamic key change capability. WPA2 provides
the latest and most robust encryption among these security methods and
thus is recommended.
Security:
WPA2 (the default), WPA or mix of WPA2/WPA.
WPA Type
802.1x uses a RADIUS (Remote Authentication Dial-In User Service) server for
user authentication. If you selected 802.1x, the following options are available:
Server IP Address:
Enter the IP address of the RADIUS Server.
Port:
Enter the port used by the RADIUS Server.
Secret:
Enter the secret used by the RADIUS Server.
Cipher Type:
Select either AES, TKIP or Both (AES/TKIP). The options vary
depending on the WPA type selected. AES is recommended as it is
more advanced than TKIP.

D-Link DSL-226 Specifications

General

Brand	D-Link
Model	DSL-226
Category	Network Router
Language	English
