79D-Link DSL-3788 User Manual
Section 6 - Connecting to a Wireless Network
Connect a Wireless Client to Your Router
WPS Button
Step 2 - Within 2 minutes, press the WPS button on your wireless device (or launch the software utility and start the WPS
process).
The easiest and most secure way to connect your wireless devices to the router is with WPS (Wi-Fi Protected Setup). Most
wireless devices such as wireless adapters, media players, Blu-ray DVD players, wireless printers and cameras will have a WPS
button (or a software utility with WPS) that you can press to connect to the DSL-3788 router. Please refer to your user manual
for the wireless device you want to connect to make sure you understand how to enable WPS. Once you know, follow the steps
below:
Step 1 - Press the WPS button on the DSL-3788 for about 5 seconds. The WPS LED on the front will start to blink.
Step 3 - Allow up to 1 minute for your connection to be congured. Once the WPS LED stops blinking, you will be connected
and your wireless connection will be secure with WPA2.
WPS Button

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DSL-3788 and is the answer not in the manual?

D-Link DSL-3788 Specifications

General IconGeneral
Ethernet WANYes
SIM card slotNo
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)866 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithmsWPA, WPA2
Product typeTabletop router
Product colorBlack
Antennas quantity2
Output current5 A
Output voltage12 V
AC input voltage100 - 240 V
Power source typeDC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)10 - 95 %
Number of products included1 pc(s)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth30.75 mm
Width210 mm
Height150 mm
Weight277.4 g
