xStack
®
DGS-3426G Layer 2 Gigabit Ethernet Managed Switch
163
Figure 3 - 62 LLDP Management Address Settings window
The following parameters can be set:
Parameter Description
Unit
Select the unit you wish to configure.
From/To Port
Use the drop-down menu to select a range of ports to be configured.
Address Type
Use the drop down menu to select either the IPv4 or IPv6 Address. IPv4/IPv6 is a management
IP so the IP information will be sent with the frame when the mgt_addr config is enabled.
Address
Enter the management ip address or the ip address of the entity you wish to advertise to.
Port State
Used to Enable or Disable the Port State for the LLDP Management Address Settings.
Click Apply to implement changes made.
