xStack
®
DGS-3426G Layer 2 Gigabit Ethernet Managed Switch
177
Figure 4 - 2 Bandwidth Settings window
The following parameters can be set or are displayed:
Parameter Description
Unit
Select the switch in the switch stack to be modified.
From/To
A consecutive group of ports may be configured starting with the selected port.
Type
This drop-down menu allows a selection between RX (receive,) TX (transmit,) and Both. This
setting will determine whether the bandwidth ceiling is applied to receiving, transmitting, or both
receiving and transmitting packets.
No Limit
This drop-down menu allows the user to specify that the selected port will have no bandwidth limit.
Enabled disables the limit.
