xStack
®
DGS-3426G Layer 2 Gigabit Ethernet Managed Switch
278
Figure 6 - 66 Multiple Authentication Settings window
The following parameters may be set:
Parameter Description
Unit
Choose the Unit ID of the switch in the switch stack you wish to configure.
From/To
Select a port or range of ports to be configured.
Authorized Mode
Use the drop down menu to select either Port Based or Host Based authorized mode.
Port Based – If one of the attached hosts passes the authentication process, all host on the
same port will be granted access to the network. If the user fails the authorization, this port will
To Next Page
