DAELIM a.four

1-13
SERVICE INFORMATION
ITEM STANDARD
BR8HSA
0.6~0.7mm
BTDC 17。±2。/1,800rpm
over 120V
over 120V
over 1.5V
0.1-0.5Ω
6.5-9.5
㏀㏀
2.6±1.25
㏀㏀
500Ω±20%
100Ω±20%
AC
12V-9.5A/5,000rpm
0.8Ω±20%
0.55Ω±20%
Semi-conductor
12.6-13.6V/5,000rpm
14.0-15.0V/5,000rpm
6.3-7.1Ω
5.5-6.5Ω
12V-35/35W
12V-5/21W
12V-10W×2
12V-10W×2
12V-1.7W
12V-3W
12V-3W
12V-3W
7A
12V-5W
MF BATTERY
12V-3AH
13.0-13.2V
0.4A/5h
4A/0.5h
USE LIMITS
IGNITION SYSTEM
SPARK PLUG STANDARD
PLUG GAP
IGNITION TIMING F MARK
PEAK VOLTAGE IGNITION COIL(PRIMARY VOLTAGE)
EXCITE COIL
PULSE GENERATOR
IGNITION COIL RESISTANCE VALUES(20℃)
PRIMARY COIL
SECONDARY COIL (PLUG CAP CONNECTION)
SECONDARY COIL (PLUG CAP DISCONNECTION)
EXCITE COIL RESISTANCE VALUE(20℃)
PLUSE GENERATOR RESISTANCE VALUE(20℃)
CHARGING SYSTEM, AC GENERATOR
AC GENERATOR TYPE
OUTPUT
CHARGING COIL RESISTANCE VALUE(20℃)
LIGHTING COIL RESISTANCE VALUE(20℃)
REGULATOR/RECTIFIER
TYPE
CONTROL VOLTAGE LAMP SIDE
CHARGING SIDE
REGISTER RESISTANCE VALUE
REGISTER(6.7Ω 5W)
REGISTER(5.9Ω 30W)
LIGHTS, METER, SWITCHES
LIGHTS, BULBS HEADLIGHT
TAIL/STOP LIGHT
WINKER LIGHTS FRONT
REAR
METER LIGHTS
HIGH BEAM PILOT
OIL PILOT
WINKER PILOTS
FUSE
LICENSE LAMP
BATTERY
TYPE
CAPACITY
TERMINAL VOLTAGE(20℃)
CHARGING CURRENT/STANDARD
CHARGING CURRENT/RAPID
