SERVICE INFORMATION
TWIST TORQUE
STANDARD TWIST TORQUE
ENGINE PARTS
TYPE
5mm BOLT, NUT
6mm BOLT, NUT
8mm BOLT, NUT
10mm BOLT, NUT
12mm BOLT, NUT
TWIST TORQUE
0.5㎏f·m
1.0㎏f·m
2.2㎏f·m
3.5㎏f·m
5.5㎏f·m
TYPE
5mm SCREW
6mm SCREW
6mm SCREW FLANGE BOLT, NUT
8mm SCREW FLANGE BOLT, NUT
10mm SCREW FLANGE BOLT, NUT
TWIST TORQUE
0.4㎏f·m
0.9㎏f·m
1.2㎏f·m
2.7㎏f·m
4.0㎏f·m
TWIST PART
FLY WHEEL NUT
DRIVE FACE NUT
CYLINDER HEAD BOLT
SPARK PLUG
DRIVEN FACE NUT
CLUTCH OUTER NUT
OIL LEVEL CHECK BOLT
EXHAUST PIPE JOINT NUT
MUFFLER BRACKET BOLT
CRANK CASE BOLT
NUMBER
1
1
4
1
1
1
1
2
2
6
TWIST TORQUE
4.0㎏f·m
5.5㎏f·m
1.0㎏f·m
1.4㎏f·m
5.5㎏f·m
4.0㎏f·m
1.3㎏f·m
1.2㎏f·m
3.3㎏f·m
1.0㎏f·m
REFERENCESCREW DIAMETER (mm)
10
12
6
14
28
10
8
6
8
6
Bolts not appearing in the following table are tightened using standard torque.
