Service Information
1-13
Item Q’ty Thread dia(mm)
Torque value
Remarks
kg.m(N.m,ft-lb)
Brake caliper bracket bolt 2 8 2.7(27, 20)
Brake caliper bleeder valve 1 8 0.6(6, 4.3)
Brake caliper slide pin (socket bolt)
1 8 2.3(23, 17)
Brake caliper pin bolt 1 8 1.8(18, 13)
Apply locking agent
Brake pad pin bolt 2 8 1.8(18, 13)
Master cylinder reservoir cap 4 4 0.13(1.3, 0.94)
Brake hose bolt 2 10 3.5(35, 25)
Brake lever pivot bolt 1 6 1.0(10, 7)
Brake lever pivot lock nut 1 6 1.0(10, 7)
Rear shock-absorber upper bolt 1 10 2.7(27, 20)
Rear shock-absorber lower bolt 1 10 4.0(40, 29)
Rear shock-absorber damper rod lock nut
2 10 3.8(38, 27)
Apply locking agent
Torque values listed above are for specific tightening points. Torque values for other items are listed in the
following table.
SH(Small Head): Indicates 6mm bolt of 8mm flange head.
Item
Torque Value
Item
Torque Value
N.m Kg-m ft-lb N-.m Kg-m ft-lb
5mm bolt, nut 5 0.5 4 5mm screw 4 0.4 3
6mm bolt, nut 10 1.0 7 6mm screw 9 0.9 7
8mm bolt, nut 22 2.2 16 6mm flange bolt, nut 9 0.9 7
10mm bolt, nut 35 3.5 25 6mm flange bolt, nut 12 1.2 9
12mm bolt, nut 55 5.5 40 8mm flange bolt, nut 27 2.7 20
10mm flange bolt, nut 40 4.0 29
