16. Ignition system
Service Information 16-1
Troubleshooting 16-2
CDI Unit Inspection 16-3
Ignition Coil Inspection 16-4
Pulse Generator Inspection 16-5
Ignition Timing Check 16-6
Side Stand Ignition Cut-off Switch
16-6
Service Information
General Safety
● Carry out inspection in sequence based on the troubleshooting table.
● If the CDI unit is dropped, or if strong shock is applied thereto, CDI unit malfunction may result. Take due
precautions when handling it. Also, if the connector or coupler is connected or disconnected when there is
current flowing, overvoltage may occur on the unit leading to circuit damage. Always turn off the main
switch prior to servicing.
● Ignition timing cannot be adjusted because the ignition system is of CDI type.
● Spark plug check. ( 3 - 5)
● Connect the same color cords. Pay particular attention to colors prior to removing wiring. Connect the
same color couplers.
● The resistance value may slightly differ from the standard values depending on each measuring situation.
Item Standard value
Primary coil 0.1~0.2Ω
Ignition coil
7.3~11kΩ
Resistance value
With plug cap
20℃(68℉)
Secondary coil
Without plug cap 3.6~4.6KΩ
Pulse generator coil resistance value 20℃(68℉) 90~150 Ω
Specifications
Tools
Measuring instruments
Digital circuit tester
PVA multi-tester
CDI tester
Spark adapter
