L. Crank Case Cover/Kick Starter/Continuously Variable Transmission
Installation
● Remove the crank case gasket, and install a new
gasket and dowel pin.
L. Crank Case Cover
Removal
● Loosen the kick starter pedal bolt.
● Remove the kick starter pedal.
● Remove the cover side cooling hose.
● Loosen the L. crank case cover bolt, and remove
the cover.
● Remove the gasket and dowel pin.
7-2
Crank case cover
Kick starter pedal
To Next Page
