8-1
8. Generator/Starter Clutch
Service Information 8-1
Shroud 8-2
A.C Generator 8-2
R.Crank Case Cover 8-4
Starter Clutch 8-6
Service Information
General Safety
● This section describes the removal and assembling of the A.C. generator.
● For information on A.C generator inspection, refer to the section 15.
● The charging system can be maintained without removing the engine.
Specifications
Item Standard value service Limit
Starter driven gear
O.D 39.622-39.635(1.5599 -1.5604) 39.53(1.556)
I.D 32.000-32.025(1.2578 -1.2588) 32.10(1.2618)
Reduction gear I.D 12.016-12.034(0.4723 -0.4730) 12.10(0.4756)
Reduction gear shaft O.D 11.966-11.984(0.4703 -0.4710) 11.97(0.4705)
Torque values
Fly wheel bolt 5.5kg.m(55N.m, 39ft-lb)
Starter clutch socket bolt 3.2kg.m(32N.m, 23ft-lb)
R. crank case cover bolt 1.1kg.m(11N.m, 8ft-lb)
Tools
Fly wheel puller
Fly wheel holder
Unit: mm(in)
8
Generator/Starter Clutch
