External Parts
4-10
Front Fender
● Loosen the flange bolt connecting the front
fender A and B.
● Loosen the 2 setting screws of the front fender A,
and remove the front fender A.
● Loosen 1 setting screw of the front fender B.
● Remove the speedometer cable guide.
● Remove the front fender B.
● Install in the reverse order of removal.
Fender B
Screw
Screw
Fender A
Bolt
To Next Page
