L. Crank Case Cover/Kick Starter/Continuously Variable Transmission
● Disassemble the kick starter driven gear.
● Disassemble the kick starter idle shaft.
Kick Starter Inspection
● Check the kick starter spindle for wear or
damage.
● Check the return spring for defects or damage.
● Check the kick starter spindle bushing and the
idle gearshaft assembly for damage.
7-5
Driven gear
Idle gear
OIL
