Maintenance Section
-143-
8. Install the new filter element. When the gasket
contacts the base, tighten it 3/4 of a turn more. Do
not overtighten.
9. Raise the lift truck, remove the blocking and lower
the lift truck.
10. Fill the crankcase. See “Refill Capacities ”.
11. Start the engine and allow the oil to fill the filter and
passages.
12. Check for oil leaks.
13. Stop the engine and measure the oil level. Maintain
the oil level to the FULL mark on the dip stick.
14. Close hood and seat assembly.
Wheel Bolts and Nuts - Inspect
Inspect Tightness
NOTICE
Do not lubricate ball seas of wheels or ball faces of
wheel nuts.
Be sure mounting faces of hub, wheel nuts and flat
mounting surfaces are clean.
Tighten wheel nuts again after 24 hours of
operation.
NOTE: Always tighten wheel lug nuts in a sequence
opposite (180°) each other.
If equipped with dual wheels, follow the same nut
tightening sequence for both wheels.
Steer Wheels
Install steer wheel. Put two nuts opposite (180°) each
other. Tighten both. Install remaining nuts. Tighten all
nuts in a sequence opposite (180°) each other. Tighten
to 440+
35 N•m (325+25 lb•ft).
Drive Wheels
Install drive wheel. Put two nuts opposite (180°) each
other. Tighten both.
Install the remaining nuts. Tighten all nuts in a sequence
opposite (180°) each other. Tighten to 600+
90 N•m
(440+
60 lb•ft).
