Specifications
CHARACTERISTICS
1 Manufacturer UNIT DOOSAN DOOSAN DOOSAN
2 Model D35S-2 G35S-2 D40S-2 G40S-2 D45S-2 G45S-2
3 Capacity at rated load center kg 3500 4000 4500
4 Lo a d center di s ta nc e mm 600 600 600
5 P owe r t ype el ect ri c , di ese l, ga s, LP- GAS diesel LP-GAS diesel LP-GAS diesel LP-GAS
6 Operator type stand-on, rider seated rider-seated rider-seated rider-seated
7 Tire type c = cushion, p = pneumatic p p p
8 Wheels (x = driven) number, front/rear X2/2 X2/2 X2/2
DIMENSIONS
9 maximum fork height with rated load mm 3000 3000 3000
10 fr ee li f t mm 155 155 155
11
Lift with STD
two - stage mast
special free lift mm
12 Fork carria ge IS O c las s lll lll lV
13 Fork s th ick ness X w idt h X l eng t h mm 50X150X1050 50X150X1050 50X150X1200
14 Ti lt of ma st fo rw ard/ba c kwa rd deg 8/10 8/10 8/10
15 length to fork face mm 3075 3135 3190
width (standard tire) mm 1365 1445 1445
16
(option : dual tire) mm 1740 1740 1740
17 mast l owe re d hei gh t mm 2225 2230 2230
18 mast extended height mm 4265 4270 4420
19 overhead guard height mm 2225 2230 2230
20
Overall dimensions
seat height mm
21 Outside turning radius mm 2770 2820 2865
22 Load moment constant (from center of front wheel to fork face) mm 561 561 561
23 90° stacking aisle add load length and clearance mm 3330 3380 3425
23a 90 ° int e rs ec tin g a is l e mm 2345 2400 2460
PERFORMANCE
24 traveling, loaded/unloaded km/h 24/25 21/22 24/25 20/21 24/25 20/21
25 lifting, loaded/unloaded mm/s 520/540 500/540 520/540 500/540 520/540 500/540
26
Speeds
lowering, loaded/unloaded mm/s 480/450 480/450 480/450
28 Drawbar pull at 1.6 km/h, loaded kg 3300 3355 3300 3430 3400 3410
30 Gradeability at 1.6 km/h, loaded % 38 36 35 33.5 32 31
31 Acceleration time traveling, loaded/unloaded s
WEIGHT
32 Total weight unloaded kg 5840 6170 6560
33 at loa de d , front/ r ea r kg 8340/1000 9050/1120 9860/1200
34
Axle load
without loaded, front/rear kg 2810/3030 2730/3440 2725/3835
CHASSIS
35 number of fr on t/rear 2/2 2/2 2/2
36 siz e, front 8.25X15-14 300X15-18 300X15-18
37
Tires
siz e, re ar 7.00X12-12 7.00X12-12 7.00X12-12
38 Wheelbase mm 2000 2000 2000
fr on t /rea r (st and ar d t ire) mm 1132/1115 1147/1115 1147/1115
39 Tread
(option dual tire) mm 1290/1115 1290/1115 1290/1115
40
loaded, at the lowest point mm 160 160 160
41
Ground clearance
loaded, at center of wheelbase mm 205 205 205
42
service brake
shoe/disc shoe/disc shoe/disc
43
Brakes
pa rk ing br ak e toggle toggle toggle
DRIVE
45 Battery voltage/capacity V/AH 24/75 12/75 24/75 12/75 24/75 12/75
49
manufacturer/model DOOSAN
/DB58
GM V6 4.3L
DOOSAN
/DB58
GM V6 4.3L
DOOSAN
/DB58
GM V6 4.3L
ra te d o utput (at rpm ) ps/rpm 92/2200 86.7/2400 92/2200 86.7/2400 92/2200 86.7/2400
50
(DIN) kW/hp
68/91 6 3.8/85.5 68/91 63.8/85.5 68/91 63.8/85.5
51 max. torque/rpm kgm/rpm 31.5/1600 30.5/1400 31.5/1600 30.5/1400 31.5/1600 30.5/1400
52 cyc l e/c y l inders /disp lac em en t cc 4/6/5785 4/6/4294 4/6/5785 4/6/4294 4/6/5785 4/6/4294
Engine
fuel consumption I/hr 6.5 - 6.5 - 6.5 -
55 ty pe powershift powershift powershift
56
Transmission
no. speeds forward/reverse 2/2 2/2 2/2
57 Operatin g p re ssu re s y s tem/ att ac hment bar 190/140 190/140 210/140
