5.11 Alarm
Click alarm function, you can see an interface is shown as Figure 5-79.
Here you can set device alarm type and alarm sound setup.
Figure 5-79
Please refer to the following sheet for detailed information.
Please make sure current device can upload the alarm.
System alarms when video loss occurs.
Camera
masking(Tampering)
System alarms when camera is viciously
masking.
System alarms when disk is full.
System alarms when disk error occurs.
Alarm input device sends out alarm.
System alarms when temperature is high.
System alarms when battery voltage is low
Check the box here, system can automatically
pops up an alarm icon on the Alarm button in
the main interface when there is an alarm.
System sends out alarm sound when an alarm
occurs. You can specify as you wish.
Here you can specify alarm sound file.
5.12 Log out
Click log out button, system goes back to log in interface. See Figure 5-80.
You need to input user name and password to login again.
