Dahua DH-DVR0804ME-HE User Manual

90
Plate Overlay
Overlay some plate information on the video.
5.9.1.2.4 Zero-Ch Encoding
The zero-channel encoding interface is shown as in Figure 5-21.
Figure 5-21
Please refer to the following sheet for detailed information.
Parameter
Function
Compression
H.264
Resolution
D1/HD1/CIF/2CIF/QCIF.
Frame Rate
1～25(30).
Bit Rate(kb/s)
640/768/896/1024.
5.9.1.2.5 Preview Overlay
The preview overlay interface is shown as in Figure 5-22. You can overlay time, speed, plate
information and etc on the device preview interface and Web monitor video.
The preview overlay is to overlay information on the preview interface or WEB monitor
video, the information is not included in record file.
Figure 5-22
