Local Configurations 254
Figure 5-216
Select the route. 2)
If there are several USB storage devices are connected to the Device, you can
select from the Device Name list.
Click Refresh to total space, free space and the file list in the selected USB
storage device.
In the case of insufficient capacity, click to delete the needless files.
Click New Folder to create a new folder in the USB storage device.
Click Apply to save the route selection settings. 3)
The Test interface is displayed again.
Click to start packet capturing and backing up. Step 5
Only the data packet of one LAN can be captured at one time.
After capturing starts, you can exit the Test interface to perform other operations
such as web login and monitoring.
Click to stop capturing. Step 6
The backup data is saved in the selected route under the naming style "LAN
name-time.pcap." See Figure 5-217. You can open it by using Wireshark software.
