Dahua ITC215-PW4I-IRLZF27135 User Manual

Device Structure 7
No.
Port
Function
Description
7
ALARM
Alarm port

Alarm output
 Brown: ALARM_NO1
 Green: ALARM_NC1
 Blue: ALARM_NO2
 White: ALARM_NC2
 Yellow: ALARM_NO3
 Orange: ALARM_NC3

Alarm input
 Purple: IO_IN1
 Pink: IO_IN2
 Red: ALARM_IN1
 Black: GND
8
Power
Power input
port
Inputs DC 12V power. Please be sure to supply power as
instructed in the Guide.
Device abnormity or damage could occur if power is not
supplied correctly.

Dahua ITC215-PW4I-IRLZF27135 Specifications

General

Brand	Dahua
Model	ITC215-PW4I-IRLZF27135
Category	Security Camera
Language	English
