Device Installation8
3 Device Installation
The actual product shall prevail. The following installation figures are for reference only.
Universal Joint Installation
UseM6× 14 screw to fix the universal joint on the bracket.
Use two 1/4-20×14UNC screws to fix the camera on the universal joint.See Figure 3-1.
Universal joint installation
Adjust the universal joint UDLR and adjust the camera location.
So far, device installation is completed.
