Set picture coding size, there are 8 levels optional; Or select Customized,
the range is from 50 to 1024.
You can select either picture quality or picture coding size to make setting.
Click OK to finish configuration.
5.4.2.2.3 ROI
It supports max 3 regions at the same time.
The bigger the image quality value is, the better the quality will be.
Click Remove All, and delete all the area boxes; Select one box, and then click delete or
right click to delete it.
Set ROI in the image, and then the selected image would display with configured quality.
Select Setting > Camera > Video > Interest Area.
The ROI interface is displayed, see Figure 5-48.
ROI
Configure parameters according to actual requirement. Please refer to Table 5-25 for
more details.
Table 5-25 ROI parameter description
