4 Device Mounting
Modular VTO consists of single module mounting, double module mounting and 3-module
mounting. Take 3-module mounting for example.
 When leaving factory by default, visiting cards and card cover have been included in the
attachment.
 When power-on after mounting, please ensure that all modules have been connected;
otherwise, they fail to work normally.
 Before installation of surface mounting box and flush mounting box, cables in the wall shall
go through the bracket or flush mounting box.
4.1 Surface Mounting
Drill holes according to hole positions of surface mounting box, and put expansion pipe Step 1
in place.
Fix surface mounting box onto the wall with ST3×18 screws. Step 2
Fix every module onto front panel with M3×6 screws. Step 3
Connect cables. Please refer to “2 Product Structure”. Step 4
Fix the front panel onto surface mounting box with M4×40 screws. Step 5
Apply glue between surface mounting box and the wall. Step 6
Write room number or the user’s name on the visiting card, and insert it into user Step 7
directory.
