Dahua NVR2104HS-P-S3 User Manual

Table 5-14 PTZ functions
Icon Function Icon Function
Preset Pan
Tour Flip
Pattern Reset
Scan
Click the AUX Cong icon to open
the PTZ functions settings page.
AUX Switch
Click the Enter Menu icon to open
the PTZ Menu page.
5.6.7.3 Conguring PTZ Functions
5.6.7.3.1 Conguring Presets
Procedure
Step 1 On the expanded PTZ control panel, click .
Figure 5-39 Preset
Step 2 Click the direction arrows to the required position.
Step 3 In the Preset box, enter the value to represent the required position.
Step 4 Click Setting to complete the preset settings.
5.6.7.3.2 Conguring Tours
Procedure
Step 1
On the expanded PTZ control panel, click .
Step 2 Click the Tour tab.
User's Manual
152
