Local Basic Operations 66
Under Copy, select All to apply the settings to all the days of a week, or select
specific day(s) that you want to apply the settings to.
3) Click Apply to save the settings.
Step 5 Click Apply to complete the settings.
Enable auto record function so that the record plan can become activated. Refer to
"4.1.4.6.3 Record control" for detailed information.
4.1.4.6.2 Snapshot Schedule
You can set schedule snapshot period.
After set schedule snapshot, device can snapshot image according to the period you set here.
For example, the alarm snapshot period is from 6:00–18:00 Monday, device can snapshot
during the 6:00–18:00 when an alarm occurs.
Step 1 Click Snapshot button, device goes to following interface. See Figure 4-39.
Select Main Menu > STORAGE > SCHEDULE > Snapshot, you can go to the
snapshot interface.
Figure 4-39
Step 2 Select a channel to set schedule snapshot.
Step 3 Set snapshot type as schedule. Refer to “4.2.5.2 Snapshot“ for detailed information.
Step 4 Check the box to set alarm type. See Figure 4-40.
Figure 4-40
When the record type is MD (motion detect), alarm, MD&Alarm, IVS and POS, enable the
channel record function when corresponding alarm occurs. For example, when the alarm
