Local Basic Operations 67
type is MD, select Main Menu > ALARM > VIDEO DETECTION > Motion Detect, select
the record channel and enable record function. See Figure 4-35.
When the record type is MD (motion detect), alarm, MD&Alarm, IVS and POS, refer to
“4.8.5 Video detect ", "4.8.3 Alarm ", " 4.7.2.4 IVS " and " Step 3 POS " for detailed
information.
Figure 4-41
Step 5 Refer to "4.1.4.6.1 Recording Schedule “ to set snapshot period.
Step 6 Click Apply button to save snapshot plan.
Enable auto snapshot function so that the snapshot plan can become activated. Refer to
"4.1.4.6.3 Record control" for detailed information.
4.1.4.6.3 Record Control
After set schedule record or schedule snapshot, you need to enable auto record and snapshot
function so that system can automatically record or snapshot.
Auto: System automatically records at the type and record period you set in Schedule
interface.
Manual: System records general files for all day.
To Next Page
