Dahua PFM906 User Manual

Page.126.
Audio test
1 channel audio signal input and 1 channel audio signal output to connect
headphones
PTZ control
Support RS485 control, Baud 600-115200bps, Compatible with more than
30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc
Color bar generator
Output one channel PAL/NTSC color bar video signal for testing monitor or
video cable.(red, green ,blue, white and black color )
UTP Cable tester
Test UTP cable connection status and display on the screen. Read the
number on the screen
Data monitor
Captures and analyzes the command data from controlling device, also can
send hexadecimal
Network test
IP address scan, link scan, and Ping test. Quickly search the for IP camera’s
IP address on your network
Cable tracer
Find a connected cable from a bundle of cables using audio tones
PoE /PSE voltage test
Measures PoE switch voltage and displays pin configuration
Digital Multi-meter
AC/DC Voltage, AC/DC current, Resistance, Capacitance, Data hold,
Relative measurement, Continuity testing . Testing speed: 3 times/ seconds,
Data range -6600～+6600.
Optical power meter
Calibrated Wavelength(nm) :850/1300/1310/1490/1550/1625nm
Power range(dBm) :-70～+10dBm
Visual fault locator
Test fiber’s bending and breakage ( SM and MM fiber)
TDR cable test
Cable’s open circuit (Breakpoint) and short circuit measurement(BNC
cable, telephone cable)
POWER
External power
supply
DC 12V 2A
Battery
Built-in 7.4V Lithium polymer battery ,5000mAh
Rechargeable
After charging 5-6 hours, normal working time 10 hours
Parameter
Operation setting
Capacitive touch screen, OSD menu, select your desired language

Dahua PFM906 Specifications

General

Brand	Dahua
Model	PFM906
Category	Test Equipment
Language	English
