Dahua PFM906 User Manual

Page.21.
(1) Connect the SDI camera's video output to the tester’s “SDI IN” interface, the image will display on
the tester. The tester only come with SDI input interface. There is no SDI output interface.
(2) Connect the SDI camera or the speed dome RS485 controller cable to the tester RS485 interface,
(Note: positive and negative connection of the cable).
3.2.4 HDMI IN
DVR or other device’s HDMI in port connect to tester’s HDMI in port, the meter will display input
image.

Dahua PFM906 Specifications

General

Brand	Dahua
Model	PFM906
Category	Test Equipment
Language	English
