Operation Manual
set alarm linkage and recording delay.
Once thepost recording(Post-Record), alarm recording continues for a long period after the
alarm ends.
Figure 5:9 recording link
5.2.2.3 Linking Snapshots
Once the snapshot linkage is set, the system can trigger the alarm and automatically take
photos when an alarm is triggered.
Previous requirements
Once the corresponding type of alarm is enabled (Normal,Movement(Motion) orAlarm
(Alarm)) , the snapshot channel links the image capture.
Set recording linkage
In the interface ofAlarm(Alarm), click snapshot and
select the channel as required.
to enable linking
Figure 5:10 snapshot link
5.2.2.4Alarm output linkage
When an alarm is triggered, the system can automatically link with the alarm output device.
In the interface ofAlarm(Alarm), click
alarm, select the channel as needed, and then setPost alarm (Post alarm).
When the alarm delay is set, the alarm continues for a long period after the alarm ends.
to enable output binding of
25
