7-Day Programmable CommerCial DigiTal ThermosTaTs
www.DaikinApplied.com 31 IM 1227 • MODELS DC THERMOSTATS
Table 7: Advanced Setup Table
Step Number Description Page Number Range Factory Default Setting
1 Prog Mode Non, 1, 5/1/1, 7 7
2 Available Modes
Heat/Cool/Auto/OFF
Heat/Cool/OFF, Heat/OFF, Cool/OFF
Heat/Cool/Auto/OFF
3 Backlight ON, OFF, 6pm-6am OFF
4 Backlight Level OFF–7 levels of brightness Level 5
5 Fan Mode Auto, ON Auto
6 Current Service Filter Runtime Hours 0–1999 0
7 Current Service Filter Calendar Days 0–1999 0
11 Current Override Hours 0–1999 0
12 Current UV Lamp Calendar Days 0–1999 0
14 Set Service Filter Runtime Hours 0–1950 0
15 Set Service Filter Calendar Days 0–720 0
16 Set UV Lamp Calendar Days 0–720 0
18 Language English, Espanol, Francais English
19 Scrolling Method
L-R Slow, L-R Fast, Word
L-R Slow, Word L-R Fast
Whole Word L Slow
Whole Word L Fast
Whole Word Ctr Slow
Whole Word Ctr Fast
Whole Word Ctr Fast
20 Setpoint Limits
No, Use, Force Program
Setpoints Frozen
No
21 Max Heat Setpoint 35° – 99° 80°
22 Min Cool Setpoint 35° – 99° 65°
23 Cycles Per Hour No Limit, 2, 3, 4, 5, 6 6
24 Compressor Minimum Off Minutes 0, 3, 5 5
25 Min. Heat/Cool Setpoint Difference 0° – 6° 2°
26 Number Of Compressor Stages 1, 2 1
27 1st Stage Deadband 1° – 6° 2°
28 2nd Stage Deadband 0° – 10° 2°
29 3rd Stage Deadband 0° – 10° 2°
30 4th Stage Deadband 0° – 10° 2°
31 Minutes Between 1st and 2nd Stage 0 – 60 2
32 Minutes Between 2nd and 3rd Stage 0 – 60 2
33 Minutes Between 3rd and 4th Stage 0 – 60 2
34 2nd Stage Turnoff Point Deadband, Setpoint Deadband
35 3rd Stage Turnoff Point Deadband, Setpoint Deadband
36 4th Stage Turnoff Point Deadband, Setpoint Deadband
37 Minutes of Fan Purge 0-3:00 0
38 Wired Sensor Use Indoor, Outdoor Outdoor
39 Control to Temp Source Tstat, Remote, Average Tstat
40 Humidity Only with Heat ON, OFF OFF
41 Fan with Humidity Demand Fan ON, Fan OFF Fan OFF
43 Cool to Dehumidify ON, OFF OFF
44 Maximum Dehum Overcool 0°–5° 2°
45 Reheat Operation w/Cool to Dehum ON, OFF OFF
55 Fan Off Delay In Seconds 0, 30, 60, 90, 120 0
56 F/C Fahrenheit, Celsius F
57 Aux Ouput Polarity Open, Closed Open
58 Aux Output Time, Temp, Ext. Error, Economizer Time
59 Aux Output Program Days 1, 5/1/1, 7 1
60 Day of Week to Program M–M MTWTFSS
61 Aux Output Start Time 12a–12a 7a
62 Aux Output Stop Time 12a–12a 9p
63 Copy Yes, No No
64 Aux Outdoor Temp Source Tstat, Outdoor, Wired Remote, Ext. Tstat
65 Aux Output Trigger Point Temp 0°–120° 65°
66 Aux Output Error Level 1-3 3
69 Comfort Recovery ON, OFF OFF
70 Dry Contact Polarity Open, Closed Open
71 Dry Contact Use Pan, Holiday Holiday
75 Humidity Polarity Open, Closed Open
76 Dehumidify Polarity Open, Closed Open
77 Light Activation ON, OFF OFF
78 Press Outdoor to Set Light Level N/A N/A
79 Press Outdoor to clean all messages N/A N/A
