IM 1227 • MODELS DC THERMOST
A
TS
32
www
.DaikinApplied.com
7-D
a
y
P
rogrammable
C
ommerCial
D
igiT
al
T
hermosT
a
Ts
T
able 8: Programming Worksheet
Day
Period
Start Time
Cool
Heat
Monday
Unoccupied
Occupied 1
Occupied 2
Occupied 3
T
uesday
Unoccupied
Copy Mon to T
ues
□
No
□
Ye
s
Occupied 1
Occupied 2
Occupied 3
Wednesday
Unoccupied
Copy Mon to T
ues
□
No
□
Ye
s
Occupied 1
Occupied 2
Occupied 3
Thursday
Unoccupied
Copy Mon to T
ues
□
No
□
Ye
s
Occupied 1
Occupied 2
Occupied 3
Friday
Unoccupied
Copy Mon to T
ues
□
No
□
Ye
s
Occupied 1
Occupied 2
Occupied 3
Saturday
Unoccupied
Copy Mon to T
ues
□
No
□
Ye
s
Occupied 1
Occupied 2
Occupied 3
Sunday
Unoccupied
Copy Mon to T
ues
□
No
□
Ye
s
Occupied 1
Occupied 2
Occupied 3
31
33
Table of Contents
Default Chapter
2
Table of Contents
2
7-Day Programmable Commercial
3
Digital Thermostats
3
Model TSTATD4271C Multi Stage 4+2
3
Unit Components
3
Display Features
4
Quick Start
5
Installation Instructions
6
Remove and Replace the Old Thermostat
6
Wire Connections
6
Explanation of Thermostat Jumpers
7
Sample Wiring Diagrams
7
Test Operation
8
User Setup
9
Backlight Operation
9
System Runtimes
10
Time Period Programming
11
Installer Setup
12
How to Change Settings in the Setup Screens
12
Locking/Unlocking the Keypad
12
Cycles Per Hour
13
Setpoint Limits
13
Dry Contact Operation
14
Model TSTATD4272C Multi Stage 4+2
15
Humidity Control, Light Activated
15
Unit Components
15
Display Features
16
Quick Start
17
Installation Instructions
18
Remove and Replace the Old Thermostat
18
Wire Connections
18
Explanation of Thermostat Jumpers
19
Sample Wiring Diagrams
20
Test Operation
21
User Setup
22
Backlight Operation
22
System Runtimes
23
Time Period Programming
24
Installer Setup
25
How to Change Settings in the Setup Screens
25
Locking/Unlocking the Keypad
25
Auxiliary Output
27
Dry Contact Operation
28
Light Activated Operation
29
Press Outdoor to Clear All Messages
29
Technician Setup
30
High Resolution Touch Screen
30
Digital Thermostat
30
Model TSTATD4272CGT with Multi Stage 4+2
33
And Humidity Control
33
Skyport™ Cloud Services Compatibility with Wi-Fi Accessories
33
Get to Know Your Thermostat
34
Dropdown Dashboard
35
Care and Use of Your Thermostat
35
Quick Start
36
Temperature, Modes & Fan
36
Main Menu Buttons
37
The Touchscreen Assistant
37
Accessories
38
Preferences
39
Security
40
Display
41
Screensaver Settings
42
Information
43
Alerts Settings
44
Set Time & Date
45
Schedule
46
Holidays
48
Fan Settings
50
Emergency Heat
50
Humidity for TSTATD4272CGT Models Only
51
Settings
52
Using the Settings Functions
54
Installation Instructions
57
Remove and Replace the Old Thermostat
57
Wire Connections
57
Thermostat Backplate
58
Wiring
59
Index
61
Troubleshooting: 7 Day Programmables
61
Troubleshooting: Touchscreens
61
Glossary
62
Warranty: 7 Day Programmables
63
Warranty: Touchscreens
64
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Daikin TSTATD4271C and is the answer not in the manual?
