SK2014‐SON‐002‐TechMnl‐FMCD‐00
3
A.5. ValveInformation
A.5.1. 2‐WayValveBody
A.5.2. 3‐WayValveBody
ValveDimensions(mm)
DN A B C D
D15(G1/2”)
52 47 19.5 63
ValveDimensions(mm)
DN A B C D
D15(G1/2”)
52 70 40 86
