Daitsu FMCD*ECM series - Master - Slave Network Setup

Page 39 of 62
SK2014‐SON‐002‐TechMnl‐FMCD‐003

C.3.2. Master–SlaveNetworkSetup

1) Disconnectthecommunicationplugfromthecontrolbox



2)Communicationplug

A,B,A,BisprintedonthemainPCB.Whenyouconnectthewires,pleaseensureconnectionofAtoAandBtoB.



3)Connectionwire

3.1) Ifthetotallengthofwireismorethan1000m,pleaseuseshieldedwireinordertoprotectthesignaltransmission.

3.2) Completewireconnection



Firstunit Middleunit Lastunit
