Page 9 of 62
SK2014‐SON‐002‐TechMnl‐FMCD‐003
A.3. CoilData
A.3.1. 2‐PipeSystems
Model
FinHeight
(mm.)
FinLength
(mm.)
FinsperInch No.ofRows No.ofCopper No.ofCircuits
Tube
Diameter
(mm)
FMCD‐04 230 680
19.5
2 8 2 7
FMCD‐06 230 680 2 14 3 7
FMCD‐12 230 680 2 22 4 7
FMCD‐15 230 680 2 22 4 7
FMCD‐18 357 680 2 34 5 7
FMCD‐20 378 845 2 36 6 7
FMCD‐24 378 845 2 36 6 7
