E. SensorResistanceR‐TConversionTable
Resistance:R(25°C)=10K
Ω
±1%
BetaConstant : B(25/85)=528K±1%
T
Rmin Rnom Rmax
T
Rmin Rnom Rmax
(KΩ) (KΩ) (KΩ) (KΩ) (KΩ) (KΩ)
‐30 174 182.7 191.8 4 26.11 26.9 27.71
‐29 163.4 171.5 179.9 5 24.85 25.59 26.34
‐28 153.6 161.1 168.9 6 23.65 24.35 25.05
‐27 144.4 151.3 158.5 7 22.52 23.17 23.83
‐26 135.8 142.2 148.9 8 21.45 22.06 22.68
‐25 127.8 133.8 140 9 20.44 21.01 21.59
‐24 120.3 125.8 131.6 10 19.48 20.02 20.55
‐23 113.3 118.4 123.8 11 18.58 19.7 19.58
‐22 106.7 111.5 116.5 12 17.71 18.18 18.65
‐21 100.6 105.1 109.7 13 16.9 17.33 17.77
‐20 94.9 99.03 103.3 14 16.12 16.53 16.94
‐19 89.51 93.39 97.41 15 15.39 15.77 16.16
‐18 84.5 88.11 91.85 16 14.69 15.05 15.41
‐17 79.8 83.17 86.64 17 14.03 14.37 14.7
‐16 75.39 78.53 81.76 18 13.41 13.72 14.03
‐15 71.26 74.18 77.19 19 12.81 13.1 13.4
‐14 67.37 70.1 72.9 20 12.24 12.52 12.79
‐13 63.73 66.26 68.88 21 11.7 11.96 12.22
‐12 60.3 62.67 65.1 22 11.19 11.43 11.67
‐11 57.08 59.28 61.55 23 10.71 10.93 11.15
‐10 54.05 56.1 58.22 24 10.24 10.45 10.66
‐9 51.19 53.12 55.08 25 9.8 10 10.2
‐8 48.51 50.3 52.14 26 9.374 9.57 9.765
‐7 45.98 47.66 49.37 27 8.969 9.16 9.351
‐6 43.61 45.17 46.77 28 8.584 8.77 8.957
‐5 41.36 42.82 44.31 29 8.218 8.4 8.582
‐4 39.25 40.61 42 30 7.869 8.047 8.225
‐3 37.26 38.53 39.83 31 7.537 7.71 7.885
‐2 35.38 36.56 37.78 32 7.221 7.39 7.56
‐1 33.6 34.71 35.85 33 6.92 7.085 7.251
0 31.93 32.97 3402 34 6.633 6.794 6.956
1 30.35 31.32 32.3 35 6.36 6.517 6.675
2 28.85 29.76 30.68 36 6.099 6.252 6.407
3 27.44 28.29 29.15 37 5.85 6 6.151
