C.5. OpenModbusprotocol

TransferMode:RTU,BAUDRate:9600bps,8databit,1stopbit,Noneparitybit

Thecommunicationsrequireadelayof80msbetweenreadingananswerandsendingthenextcommand.Alltemperaturesare
equaltoreadingdata*10accuracy:0.1degreeC.

SupportedFunctions:

FunctionCode FunctionDescription
01(01H) ReadCoils
02(02H) ReadDiscreteInputs
03(03H) ReadHoldingRegisters
04(04H) ReadInputRegisters
05(05H) WriteSingleCoil
06(06H) WriteSingleRegister
15(0FH) WriteMultipleCoils
16(10H) WriteMultipleRegisters
255(FFH) ExtendedCommandswhichare usedtotest unit

ValidErrorcodetable:

Errorcode Description Definition
01(01H) Invalidcommands Receivedcommandsbeyondvalidcommands
02(02H) Invaliddataaddress Dataaddressesbeyondvaliddataaddress
03(03H) Invaliddata Databeyonddefinitionrange
04(04H) Writedatanotsuccessful Writedatadid notsucceed
